ZM-S1500

15” TFT-LED Touch Monitor

ZM-S1500 15” TFT-LED Touch Monitor
ZM-S1500 15” TFT-LED Touch Monitor
ZM-S1500 15” TFT-LED Touch Monitor
ZM-S1500 15” TFT-LED Touch Monitor
The 15” TFT-LED Touch Monitor is a professional-grade display engineered for reliability in demanding commercial and industrial environments. Its compact 4:3 aspect ratio and 1024 x 768 resolution make it a perfect fit for point-of-sale systems and self-service kiosks where space and clarity are essential.
Equipped with P-CAP 10-point Multi-Touch technology, the monitor provides a responsive, consumer-grade touch experience. The true-flat bezel design offers a modern aesthetic while ensuring the surface is easy to clean and maintain, even in high-traffic retail or medical settings.
Built for 24/7 continuous operation, this display features versatile connectivity including VGA, DP, and optional HDMI. Its energy-efficient LED backlight and wide operating temperature range make it a durable, cost-effective solution for any professional hardware integration.

• 15” TFT-LED (1024 x 768)
• P-CAP 10-Point Touch
• VGA / DP / HDMI (Opt.)
• 300 nits Brightness
• Low Power (<30W)
• 0°C ~ 45°C Operating
• True-Flat Bezel
• VESA / Desktop Mount

Specifications

Power Consumption
30W Max.
Power Adaptor
Input: AC 90 ~ 240VAC; Output: DC 12V/4A
Power Saving Mode
Less than 2W
Turn Off Mode
Less than 0.3W
Operating Temperature
0 ~ 45°C
Option Accessory
Desktop Stand
LCD Panel
15” TFT-LED Panel
Resolution
1024 x RGB x 768
Display Active Area
304.1 × 228.1 mm
Response Time
10 ms typ.
Brightness
300 cd/m² typ.
Plug and Play
DDC1/2B (Analog); DDC2B (Digital)
Touch Screen
P-CAP Multi-Touch (1-10 points) Weida
Interface
USB
Video Input
1x VGA, 1x DP, 1x HDMI(Optional)
Audio
1x Audio Port
USB
1x USB (For touch)
Power Connector
1x DC-in, 1x DC-out
