Z-3102 是 ZEBEX 中階手持式 2D 影像掃描器系列的增強版，可提升您的掃描體驗。該設備引入了精心設計的尖端功能，旨在改變您的掃描過程並將您的效率提升到非凡的水平。 Z-3102 採用先進的影像處理技術，擅長從任何方向高速讀取一維、二維和郵政條碼，並採用人體工學設計，提高用戶舒適度，並且功耗低。
• 流線型設計與大板機，操作輕鬆
• 捕捉手機、平板電腦或電腦螢幕上的條碼
• 高速、全方位讀取一維、二維和郵政條碼
• 極低的功耗
• 經濟實惠的高性能
| Aiming Element | ||
|---|---|---|
| 617 nm LED | ||
| Illumination Element | ||
| White LED | ||
| Optical System | ||
| CMOS | ||
| Image Sensor | ||
| 1280 × 800 | ||
| Depth of Field | ||
| Code39 ( 4 mil ) : 30 - 130 mm Code39 ( 5 mil ) : 30 - 160 mm EAN 13 ( 13 mil ) : 30 - 300 mm QR Code ( 7 mil ): 30 - 125 mm Data Matrix ( 7 mil ): 40 - 130 mm (Note: DOF may vary depending on environment condition and barcode quality.) | ||
| Min. Bar Width | ||
| 4 mils (Code39) | ||
| Print Contrast | ||
| 30% @ UPC/EAN 100% | ||
| Indicator | ||
| Blue LED | ||
| Beeper Operation | ||
| Programmable tone & beep time | ||
| System Interface | ||
| RS-232, USB | ||
| Dimensions H x W x L | ||
|---|---|---|
| 152.3 x 64.4 x 104.9 mm (device only) | ||
| Weight (g) | ||
| 86.5 g (device only) | ||
| Cable | ||
| Standard 2M straight | ||
| Input Voltage | ||
|---|---|---|
| 5 VDC ±10% | ||
| Operating Current | ||
| 150 mA @ 5V ( Typical ) | ||
| EMC | ||
|---|---|---|
| CE & FCC DOC compliance, VCCI, BSMI, UKCA | ||
| Safety | ||
| IEC 62471 | ||
| Operating Temperature | ||
|---|---|---|
| 0°C ~ 50°C ( 32°F ~ 122°F ) | ||
| Storage Temperature | ||
| -20°C ~ 60°C ( -4°F ~ 140°F ) | ||
| Humidity | ||
| 5%~95% RH (non condensing) | ||
| Light Level | ||
| 0 to 100,000 lux | ||
| Drop Durability | ||
| Designed to withstand 1.5M drops | ||
| 1D Barcode | ||
|---|---|---|
| UPC/EAN (UPCA/UPCE/ EAN-8/ EAN-13), Code 128, Code 93, Code 39, Code 32, Code 11, Codabar, Plessey, MSI, 2 of 5 (Interleaved, IATA, , Matrix, Straight), Pharmacode, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Limited | ||
| 2D Barcode | ||
| PDF417, Micro PDF417, Data Matrix, QR Code (Standard, Micro), Aztec, MaxiCode, DotCode | ||
